Mondraker
Foxy R - Deep Purple/Flame Red
$4,899.00
$7,599.00
THE FOXY R COMES BUILT UP WITH A 6061 ALLOY STEALTH EVO ALUMINIUM FRAME WITH HYDROFORMED TUBES
The FOXY R comes built up with a 6061 ALLOY STEALTH EVO aluminium frame with hydroformed tubes. Its uses our prestigious ZERO SUSPENSION SYSTEM, as well as having FORWARD GEOMETRY; a benchmark for current bikes. It’s got 160mm travel at the front and 150mm at the rear, using an Öhlins TTX fork complimented by TTX Air shock from the same brand at the back. It also highlights SRAM’s NX Eagle/SX Eagle 12-speed drivetrain, e*thirteen’s LG1 Plus Enduro wheels, and is rounded off with SRAM’s G2 brakes and ONOFF components.
| 01. Frame | Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System |
| 02. Sizes | S: 380mm / M: 420mm / L: 470mm / XL: 510mm |
| 03. Rear Shock | Ohlins TTX Air 205x62.5mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings |
| 04. Shock Settings | C20 compression, R35 rebound |
| 05. Fork | Ohlins RXF 36 M.2 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber |
| 06. Headset | Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreesx45 degrees, bottom 51.9x40x8x45 degreesx45 |
| 07. Stem | Onoff Sulfur FG 30mm 0 degrees, 6061 forged alloy, 31.8mm barbore |
| 08. Handlebar | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degrees backsweep, 5 degrees upsweep, 31.8mm barbore |
| 09. Grips | Onoff Diamond, 1lock-on, 135mm |
| 10. Seatpost | Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L size: 425x150mm, XL size: 465x170mm |
| 11. Saddle | SDG BEL-AIR 3.0, LPU foam, steel rails |
| 12. Front Brake | Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| 13. Rear Brake | Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| 14. Brake Lever | Sram G2 R, SwingLink, tool-free reach adjust |
| 15. Rims | DT Swiss E1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes |
| 16. Spokes | DT Champion, straightpull |
| 17. Front Hub | DT 370, Boost 15x110mm, IS 6 bolts |
| 18. Rear Hub | DT 370, Boost 12x148mm, 18T Ratched LN system, IS 6 bolts |
| 19. Front Tyre | Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead |
| 20. Rear Tyre | Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead |
| 21. Crankset | Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm |
| 22. Chainring | 32T, CNC-machined alloy, X-SYNC 2 |
| 23. Bottom Bracket | Sram DUB BSA, sealed bearings, 73mm |
| 24. Pedals | - |
| 25. Chain | Sram SX Eagle, 12s, Powerlock |
| 26. Front Derailleur | - |
| 27. Rear Derailleur | Sram NX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| 28. Shift Levers | Sram Trigger SX Eagle, 12s, X-Actuation 1:1 |
| 29. Cassette | Sram XG-1230, 11-50T, 12s |
| 30. Hanger | M068 |
